ELEVATOR DIMENSIONS

Use the measurements below when planning equipment moves, large deliveries, or oversized load-ins. All measurements are slightly conservative by up to 1 inch from exact to account for real-world clearance.

These measurements are not exact. They are slightly smaller than actual by up to 1 inch, giving you a small amount of leeway. When in doubt, verify on-site before your event.

Door Opening

Height of Door Opening

83"

6 ft 11 in

Width of Door Opening

42"

3 ft 6 in

Inside the Elevator

Interior Height

93"

7 ft 9 in

Interior Width

79"

6 ft 7 in

Cross Measurement (Corner to Corner)

96"

8 ft

Estimated Depth (calculated)

~54"

approx. 4 ft 6 in. Calculated from width and cross measurement. Not a verified field measurement.

Usable Depth (accounting for rear handrail)

~51 to 52"

approx. 4 ft 3 to 4 in. The stainless grab rail protrudes approximately 2.5 to 3 inches from the rear wall. Verify on-site for oversized loads.

Load Capacity

3,000 lbs

Maximum rated load capacity.
